Operating angle

Approx. 20°

Operating force

10～28N

Mechanical life expectancy

5,000,000

Operating temperature

-20℃~+70℃

Storage temperature

-20℃~+70℃

Vibration

10~55Hz 98m/s²

Shock

294m/s² (11ms)

Mass

Approx. 1500g

Protection degree

IP54

Standard resistance

10KΩ±20%

Independent linearity tolerance

±3%

Resolution ratio

Essentially infinite

Effective electrical angle

Approx. 100°

Power rating

0.4W

Output smoothness

< Against input voltage 0.2%

Contact resistance variation

<5%CRV

Insulation resistance

>1000MΩ (500V.D.C)

Dielectric strength

1 min (500V.A.C)

Electrical specifications (Switch)

Microswitch

Rating

250V.A.C./5A

Life expectancy

10,000

Insulation resistance

>100MΩ (500V.D.C.)

Dielectric strength

1min (1000V.A.C.)

Color

Red，Black，White

Title

VCC，GND，OUT

Electrical specifications

POT.with other resistance(1K, 2K, 5K, etc.), special output characteristic, speical cable length, etc.

Other special specifications

With matching signal module
